Description
General Introduction:
The Rayoptek RT-FA0G13-C00 is a Four-Channel, Pluggable, Parallel, Fiber-Optic QSFP28
Transceiver for 100G Ethernet Applications. The QSFP28 full-duplex optical module offers
4 independent transmit and receive channels, each capable of 26Gbps operation for an aggregate data rate of 104Gbps 2km using single mode fiber. These modules are designed to operate over single mode fiber systems using DFB laser array. An optical fiber ribbon cable with an MPO/MTPTM connector can be plugged into the QSFP28 module receptacle. QSFP28 PSM4 is one kind of parallel transceiver which provides increased port density and total system cost savings.
Products Name:
4X25.78125G QSFP28 PSM4, MPO connector, 2km over single mode Fiber
Product Features:
1).Four-channel full-duplex transceiver modules
2).Transmission data rate up to 26Gbit/s per channel
3).Up to 2km transmission of single mode fiber
4).Low power consumption <3.5W
5).Operating case temperature 0ºC to 70ºC
6).3.3V power supply voltage
7).RoHS 6 compliant
8).Hot Pluggable QSFP28 form factor
9).Single MPO connector receptacle
10). Built-in digital diagnostic function
Applications:
1).100G Ethernet
2). Proprietary High Speed
3). Interconnections
4). Data center
Electrical Characteristics:
Optical Characteristics:
Digital Diagnostic Functions:
The following digital diagnostic characteristics are defined over the normal operating conditions unless otherwise specified.
The Rayoptek RT-FA0G13-C00 is a Four-Channel, Pluggable, Parallel, Fiber-Optic QSFP28
Transceiver for 100G Ethernet Applications. The QSFP28 full-duplex optical module offers
4 independent transmit and receive channels, each capable of 26Gbps operation for an aggregate data rate of 104Gbps 2km using single mode fiber. These modules are designed to operate over single mode fiber systems using DFB laser array. An optical fiber ribbon cable with an MPO/MTPTM connector can be plugged into the QSFP28 module receptacle. QSFP28 PSM4 is one kind of parallel transceiver which provides increased port density and total system cost savings.
Products Name:
4X25.78125G QSFP28 PSM4, MPO connector, 2km over single mode Fiber
Product Features:
1).Four-channel full-duplex transceiver modules
2).Transmission data rate up to 26Gbit/s per channel
3).Up to 2km transmission of single mode fiber
4).Low power consumption <3.5W
5).Operating case temperature 0ºC to 70ºC
6).3.3V power supply voltage
7).RoHS 6 compliant
8).Hot Pluggable QSFP28 form factor
9).Single MPO connector receptacle
10). Built-in digital diagnostic function
Applications:
1).100G Ethernet
2). Proprietary High Speed
3). Interconnections
4). Data center
Electrical Characteristics:
| Parameter Test Point Min Typical Max Unit Notes | ||||||
| Differential input impedance | Zin | 90 | 100 | 110 | ohm |
|
| Differential Output impedance | Zout | 90 | 100 | 110 | ohm |
|
| Differential input voltage amplitude | ΔVin | 300 |
|
1100 | mVp-p |
|
| Differential output voltage amplitude | ΔVout | 300 |
|
800 | mVp-p |
|
| Input Logic Level High | VIH | 2.0 |
|
VCC | V |
|
| Input Logic Level Low | VIL | 0 |
|
0.8 | V |
|
| Output Logic Level High | VOH | VCC-0.5 |
|
VCC | V |
|
| Output Logic Level Low | VOL | 0 |
|
0.4 | V |
|
Optical Characteristics:
| Parameter Symbol Min Typical Max Unit Notes | ||||||
| Transmitter | ||||||
| Center Wavelength | λC | 1295 |
|
1325 | nm | 1 |
| RMS Spectral Width | λrms | - |
|
3.5 | nm | 1 |
| Average Launch Power, each lane | PAVG | -6 | -0.5 | +2.0 | dBm |
|
| Optical Modulation Amplitude (OMA) | POMA | -5 | -0.5 | +2.2 | dBm | 1 |
|
Difference in Launch Power between any two lanes |
Ptx,diff |
|
|
5.0 |
dB |
|
|
Transmitter and dispersion penalty (TDP), each lane (max) |
TDP |
|
|
2.9 |
dBm |
1 |
| Rise/Fall Time | Tr/Tf |
|
|
30 | ps |
|
| Extinction Ratio | ER | 3.5 |
|
|
dB |
|
| Relative Intensity Noise | Rin |
|
|
-128 | dB/Hz |
|
Digital Diagnostic Functions:
The following digital diagnostic characteristics are defined over the normal operating conditions unless otherwise specified.
