Description
General Introduction: By taking advantage of advanced polishing technology and mass production, Broadband mirrors are really cost-effective products with good optical properties.
Products Name: Economy Round Broadband Dielectric Mirrors
Alias: Borofloat mirror, Borofloat 33 mirrors, Borofloat broadband dielectric mirrors, Borofloat broadband mirrors, etc
Mirrors Substrates:
Borofloat 33
Coating:
Dielectric coating
Main Applying:
Main Characters:
1).RS, AVG > 99% in 488-694 nm or 700-950 nm wavelength range
2).Flatness and surface quality of substrate are λ /10, 40-20
3).Applicable diameter: 12.7 mm, 25.4mm
4).Special high damage threshold all media film
5).Ideal choice for medical equipment manufacturers and general laboratory applications
Products Highlights:
1).Different grades materials for option.
2).High precision & high surface roughness;
3).Sizes can be customized as per the customers' request
4).Quick lead time and delivery time.
5).Matching super optics custom and processing capacity, including Moulding, CNC machining, Polishing, Particle beam processing, Magnetic flux conversion processing, Grinding, Coating, Lightweighting, Custom Shaping, Counterbores, Drilling & Coring, Edge & Bevel Polishing,3D Contouring, Bevels & Chamfers, Steps & Slots, Laser Cutting & Marking, Metrology & Inspection, Precision Pitch Polishing, Double-Sided Polishing, Optical Assembly, Measuring, etc.
6).Excellent post-sale quality warranty, with "3R"-return, replace & refund policy
Main Optical Tech Specification:
Popular Physical Size Specification:
Main Cooperation Materials Manufacturers:
CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,ETC
Main Export Countries & Areas:
Products Name: Economy Round Broadband Dielectric Mirrors
Alias: Borofloat mirror, Borofloat 33 mirrors, Borofloat broadband dielectric mirrors, Borofloat broadband mirrors, etc
Mirrors Substrates:
Borofloat 33
| Optional I: |
Borofloat 33 from CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,ETC |
| Optional II: |
Equivalent Borofloat 33 Made in China, C-laser own brands |
Coating:
Dielectric coating
Main Applying:
| Applying Fields I: | Medical device manufacturers |
| Applying Fields II: | General laboratory use |
| ***** |
|
Main Characters:
1).RS, AVG > 99% in 488-694 nm or 700-950 nm wavelength range
2).Flatness and surface quality of substrate are λ /10, 40-20
3).Applicable diameter: 12.7 mm, 25.4mm
4).Special high damage threshold all media film
5).Ideal choice for medical equipment manufacturers and general laboratory applications
Products Highlights:
1).Different grades materials for option.
2).High precision & high surface roughness;
3).Sizes can be customized as per the customers' request
4).Quick lead time and delivery time.
5).Matching super optics custom and processing capacity, including Moulding, CNC machining, Polishing, Particle beam processing, Magnetic flux conversion processing, Grinding, Coating, Lightweighting, Custom Shaping, Counterbores, Drilling & Coring, Edge & Bevel Polishing,3D Contouring, Bevels & Chamfers, Steps & Slots, Laser Cutting & Marking, Metrology & Inspection, Precision Pitch Polishing, Double-Sided Polishing, Optical Assembly, Measuring, etc.
6).Excellent post-sale quality warranty, with "3R"-return, replace & refund policy
Main Optical Tech Specification:
| Tech Data | Description |
| Wavelength Range | 488-694 nm/700-950 nm |
| Angle of Incidence | 0-45° |
| Coating Type | Dielectric coating |
| Reflectivity |
RS, avg>99%, RP, avg>98% @ 488-694 nm RS, avg>99%, RP, avg>97% @ 700-950 nm; Ravg>80% @ 632.8 nm |
| Damage Threshold |
500 W/cm² CW 3 J/cm² @10 ns, 10 Hz, 532 nm 1000 W/cm² CW 4 J/cm² @10 ns, 10 Hz, 800 nm |
| Material | Borofloat 33 |
| Surface Quality | 40-20 scratch-dig |
| Surface Flatness | λ/10 at 632.8 nm with power removed |
| Clear Aperture | - |
| Chamfers | 0.25-0.76 mm face width |
| Chamfers Angle Tolerance | 45° ±15° |
| Wedge | - |
Popular Physical Size Specification:
| Mirror Size | 12.7mm/25.4mm/50.8mm or custom manufacturing |
| Thickness | 3.1mm,6.0mm or custom manufacturing |
| Thickness Tolerance | ±0.25 mm,or custom |
| Diameter | 12.7mm/25.4mm/50.8mm or custom manufacturing |
| Diameter Tolerance | +0/-0.13 mm |
Main Cooperation Materials Manufacturers:
CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,ETC
Main Export Countries & Areas:
Usa, Uk, Japan, Germany, Spain, France, Swiss, Korea, Russia, Pakistan, India, Portugal, Canada, New Zealand, Australia, Saudi Arab, Turkey, Finland, Poland ,etc.
Raytekoptics Extra value added services offered:
1). Optical workcraft & process solution design;
2). Rough processing raw materials;
3). Semi finishing raw materials;
4). Fabricate custom sizes and shapes;
5). Design and supply custom coatings;
6). Modify and resurface customer supplied materials;
7). Drill holes, notch glass and provide beveled substrates;
8). Precision polish optics with non-standard aspect ratios;
Payment Method: by T/T or Western Union.
Delivery time: 7-10 days.
Quality Warranty: Ruitaiphotoelectric(Raytekoptics) offers quality warranty for our optics products with "3R" policy. For any inferior-quality products, Ruitaiphotoelectric(Raytekoptics) is responsible for return, replacement and refund.
