Description
General Introduction: Raytek Quartz wafer is the most widely used optical material, because of its high purity, low coefficient of thermal expansion, high tensile strength, high light transmission and unique electrical properties.
Raytek quartz wafer is a kind of silicon wafer used in making silicon semiconductor circuit, and its raw material is silicon. After dissolving the high-purity polycrystalline silicon, it is doped with silicon crystal seeds, and then slowly pulled out to form cylindrical monocrystalline silicon. After grinding, polishing and slicing, silicon wafer is formed. At present, the most popular quartz wafer production lines are 8-inches and 12 inches.
Products Name: Quartz Wafer/Fused Silica Wafer/Quartz Glass Wafer/Semiconductor Quartz Wafer
Alias:Quartz Wafer, Quartz Crystal, Quartz Glass Wafer,Semiconductor Quartz Wafer, Fused silica wafer, Fused silica crystal, Quartz Silicon Wafer,Integrated circuit quartz wafer,Chips quartz Wafer, MEMS quartz wafer, JGS1 quartz wafer, JGS2 quartz wafer, JGS3 quartz wafer, Fused silica quartz wafer, single crystal quartz wafer, etc
Main Applying:
Main Highlights:
1). High temperature resistance
2). Excellent thermal conductivity
3). Good corrosion resistance
4). Excellent mechanical properties
5). Super insulation
6). High optical transmission efficiency
Main Technical Data:
Main Size Specification:
The listed prices are only for reference. The final price is up to the substrate type, substrate grade, product size, suface finish, surface quality and Physical & Optical request standards.
Main Cooperation Materials Manufacturers:
CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,J-FIBER,ETC
Main Export Countries & Areas:
Raytek quartz wafer is a kind of silicon wafer used in making silicon semiconductor circuit, and its raw material is silicon. After dissolving the high-purity polycrystalline silicon, it is doped with silicon crystal seeds, and then slowly pulled out to form cylindrical monocrystalline silicon. After grinding, polishing and slicing, silicon wafer is formed. At present, the most popular quartz wafer production lines are 8-inches and 12 inches.
Products Name: Quartz Wafer/Fused Silica Wafer/Quartz Glass Wafer/Semiconductor Quartz Wafer
Alias:Quartz Wafer, Quartz Crystal, Quartz Glass Wafer,Semiconductor Quartz Wafer, Fused silica wafer, Fused silica crystal, Quartz Silicon Wafer,Integrated circuit quartz wafer,Chips quartz Wafer, MEMS quartz wafer, JGS1 quartz wafer, JGS2 quartz wafer, JGS3 quartz wafer, Fused silica quartz wafer, single crystal quartz wafer, etc
Main Applying:
| Applying 1 | Laser systems/Laser optics |
| Applying 2 | All types of sensors and chips |
| Applying 3 | Optical windows and lens |
| Applying 4 | high frequency circuit / microwave circuit/Integrated circuit |
| Applying 5 | Internet of things array |
Main Highlights:
1). High temperature resistance
2). Excellent thermal conductivity
3). Good corrosion resistance
4). Excellent mechanical properties
5). Super insulation
6). High optical transmission efficiency
Main Technical Data:
| Technical Data | Description & Value |
| Substrate | Corning 7980, Nikon, Heraeus etc quartz glass or fused silica quartz |
| Size | 2, 3, 4, 5, 6, 8, 10, 12 inches,etc or customize as per demand |
| Thickness | 0.5, 1, 2, 3, 4, 6,7,8mm ,or customize as per demand |
| Polishing Workcrafts | Single surface polishing or double -surface polishing |
| Thickness Variation(TTV) | <3um |
| PPV | <=20um |
| Purity of quartz wafer |
1). synthetic quartz wafer 99.999% 2). high purity quartz wafer 99.99% |
| Quartz Wafer Design | ODM/OEM available |
Main Size Specification:
| Data | 4 inch | 5 inch | 6 inch | 8 inch | 12 inch |
| Diameter | 100 ± 0.1 mm | 125 ± 0.1 mm | 150 ± 0.1 mm | 200 ± 0.1 mm | 300± 0.1 mm |
| Thickness |
500 ± 5 um or Customize |
625 ± 5 um or Customize |
675 ± 5 um or Customize |
725 ± 5 um or Customize |
900± 5 um or Customize |
| Roughness | Ra ≤ 1 nm | Ra ≤ 1 nm | Ra ≤ 1 nm | Ra ≤ 1 nm | Ra ≤ 1 nm |
| Warpage | ≤ 10um | ≤ 10um | ≤ 10um | ≤ 10um | ≤ 10um |
| Planeness | ≤ 3 um | ≤ 3 um | ≤ 3 um | ≤ 3 um | ≤ 3 um |
| Surface Quality | 20/10 | 20/10 | 20/10 | 20/10 | 20/10 |
| Shape | Round, with locating edge and locating angle | ||||
| Chamfering | 45°, SEMI Spec; C Shape | ||||
| Substrate | Corning, Nikon, Heraeus etc. | ||||
Main Cooperation Materials Manufacturers:
CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,J-FIBER,ETC
Main Export Countries & Areas:
Usa, Uk, Japan, Germany, Spain, France, Swiss, Korea, Russia, Pakistan, India, Portugal, Canada, New Zealand, Australia, Saudi Arab, Turkey, Finland, Poland ,etc.
Raytekoptics Extra value added services offered:
1). Optical workcraft & process solution design;
2). Rough processing raw materials;
3). Semi finishing raw materials;
4). Fabricate custom sizes and shapes;
5). Design and supply custom coatings;
6). Modify and resurface customer supplied materials;
7). Drill holes, notch glass and provide beveled substrates;
8). Precision polish optics with non-standard aspect ratios;
Payment Method: by T/T or Western Union.
Delivery time: 7-10 days.
Quality Warranty: Ruitaiphotoelectric(Raytekoptics) offers quality warranty for our optics products with "3R" policy. For any inferior-quality products, Ruitaiphotoelectric(Raytekoptics) is responsible for return, replacement and refund.
