Description
Product Description:A corner cube is a retroreflective glass element that retroreflects an incident light beam at three 90° angles. These glass angles must be within a few seconds of accuracy, but the incident surface can have errors of more than 5" without appreciably affecting the performance of the corner cube.The advantage of the corner cube prism is that the prism is not sensitive to the incident angle of the incident light, and the incident light or image will be reflected by 180° within a certain range of incident angle, which is an ideal reflective optical element.
Product data:
Material: N-BK7; Fused Silica etc.
Size φ: 3.0mm~50.8mm
Dimensional tolerance: +0.0/-0.2 mm / +0.0/-0.05 mm
Beam Angle Accuracy: ±10″ / ±5″
Surface (within 25.4mm): λ/4@632.8nm / λ/8@ 632.8nm
Finish: MIL60-40
Effective aperture: 85%
Product data:
Material: N-BK7; Fused Silica etc.
Size φ: 3.0mm~50.8mm
Dimensional tolerance: +0.0/-0.2 mm / +0.0/-0.05 mm
Beam Angle Accuracy: ±10″ / ±5″
Surface (within 25.4mm): λ/4@632.8nm / λ/8@ 632.8nm
Finish: MIL60-40
Effective aperture: 85%
Chamfer (face width × 45°): 0.2~0.4mm or customer specified
Main Cooperation Materials Manufacturers:
CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,ETC
Main Export Countries & Areas:
Usa, Uk, Japan, Germany, Spain, France, Swiss, Korea, Russia, Pakistan, India, Portugal, Canada, New Zealand, Australia, Saudi Arab, Turkey, Finland, Poland ,etc.
Raytekoptics Extra value added services offered:
1). Optical workcraft & process solution design;
2). Rough processing raw materials;
3). Semi finishing raw materials;
4). Fabricate custom sizes and shapes;
5). Design and supply custom coatings;
6). Modify and resurface customer supplied materials;
7). Drill holes, notch glass and provide beveled substrates;
8). Precision polish optics with non-standard aspect ratios;
Payment Method: by T/T or Western Union.
Delivery time: 7-10 days.
Quality Warranty: Ruitaiphotoelectric(Raytekoptics) offers quality warranty for our optics products with "3R" policy. For any inferior-quality products, Ruitaiphotoelectric(Raytekoptics) is responsible for return, replacement and refund.
