Zerodur Broadband Metallic Mirrors/Zerodur Metallic Mirror/Metal Coating Mirror/Metal Lens

Description

General Introduction: Raytek broadband metal film reflector has excellent versatility, and the broadband reflector can cover ultraviolet, visible and infrared light. The nominal thermal expansion of the zerodur substrate is zero. Such extraordinary stability is essential for applications requiring diffraction limit properties
Products Name: Zerodur Broadband Metallic Mirrors
Alias: Zerodur Broadband Metallic Mirrors, Zerodur Metallic Mirrors, Zerodur Metallic Reflector, Zerodur Metallic optical mirrors, Zerodur Aluminizing Mirrors, etc
Mirrors Substrates:
Zerodur


Coating:
Metal coatings covering UV-IR spectrum
Main Applying:
Main Characters:
Zerodur is a unique glass-ceramic material with almost zero coefficient of thermal expansion and excellent uniformity in the whole material. Therefore, the mirror substrate of zerodur is the best choice when extreme thermal stability is needed or when temperature fluctuation is large. In addition, the high stability of zerodur is critical for applications requiring diffraction limit properties
1).Four metal coatings covering UV-IR spectrum
2).Substrate flatness and surface quality are λ / 5, 20-10 to λ / 20, 10-2
3).Applicable diameter: 25.4 mm to 203.2 mm
4).The nominal thermal expansion of the zerodur substrate is zero
5).Wider bandwidth and lower price than dielectric coating
6).It is insensitive to polarization and incident angle
Products Highlights:
1).Different grades materials for option.
2).High precision & high surface roughness;
3).Sizes can be customized as per the customers' request
4).Quick lead time and delivery time.
5).Matching super optics custom and processing capacity, including Moulding, CNC machining, Polishing, Particle beam processing, Magnetic flux conversion processing, Grinding, Coating, Lightweighting, Custom Shaping, Counterbores, Drilling & Coring, Edge & Bevel Polishing,3D Contouring, Bevels & Chamfers, Steps & Slots, Laser Cutting & Marking, Metrology & Inspection, Precision Pitch Polishing, Double-Sided Polishing, Optical Assembly, Measuring, etc.
6).Excellent post-sale quality warranty, with "3R"-return, replace & refund policy
Main Optical Tech Specification:
Popular Physical Size Specification:
Main Cooperation Materials Manufacturers:
CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,ETC
Main Export Countries & Areas:
Usa, Uk, Japan, Germany, Spain, France, Swiss, Korea, Russia, Pakistan, India, Portugal, Canada, New Zealand, Australia, Saudi Arab, Turkey, Finland, Poland ,etc.

Raytekoptics Extra value added services offered:
1). Optical workcraft & process solution design;
2). Rough processing raw materials;
3). Semi finishing raw materials;
4). Fabricate custom sizes and shapes;
5). Design and supply custom coatings;
6). Modify and resurface customer supplied materials;
7). Drill holes, notch glass and provide beveled substrates;
8). Precision polish optics with non-standard aspect ratios;
Payment Method: by T/T or Western Union.
Delivery time: 7-10 days.
Quality Warranty: Ruitaiphotoelectric(Raytekoptics) offers quality warranty for our optics products with "3R" policy. For any inferior-quality products, Ruitaiphotoelectric(Raytekoptics) is responsible for return, replacement and refund.
