100g Qsfp28 Sr4, MPO Connector, 70m on Om3/Optical Fiber Connector

Description

General Introduction:
The Rayoptek RT-FA0G13-C00 is a Four-Channel, Pluggable, Parallel, Fiber-Optic QSFP28
Transceiver for 100G Ethernet  Applications. The QSFP28 full-duplex optical module offers
4 independent transmit and receive channels, each capable of 26Gbps operation for an aggregate data rate of 104Gbps 2km using single mode fiber. These modules are designed to operate over single mode fiber systems using  DFB laser array. An optical fiber ribbon cable with an MPO/MTPTM connector can be plugged into the QSFP28 module receptacle. QSFP28 PSM4 is one kind of parallel transceiver which provides increased port density and total system cost savings.
General Introduction:
The Rayoptek RT-MA0S85-C00 is a Four-Channel, Pluggable, Parallel, Fiber-Optic QSFP28
Transceiver for IEEE 802.3bm,100GBASE SR4 Applications. The QSFP28 full-duplex optical module offers 4independent transmit and receive channels, each capable of 25.78125Gbps operation for an aggregate data rate of 103.125Gbps 70m using OM3 fiber. These modules are designed to operate over multimode fiber systems using850nm VCSEL laser array. An optical fiber ribbon cable with an MPO/MTPTM connector can be plugged into the QSFP28 module receptacle. QSFP28 SR4 is one kind of parallel transceiver which provides increased port density and total system cost savings.
Products Name:
100G QSFP28 SR4,MPO connector,70M on OM3
Product Features:
1).Four-channelfull-duplextransceiver modules
2).Transmissiondatarateupto25.78125Gbit/s perchannel
3). Upto70mon OM3 Multimode Fiber(MMF) and 100m on OM4 MMF
4). Lowpowerconsumption<2.5W
5). Operatingcasetemperature0ºCto70ºC
6). 3.3Vpowersupplyvoltage
7). RoHS6compliant
8). HotPluggableQSFP28formfactor
9). MPOconnectorreceptacle
10). Built-indigitaldiagnosticfunction
Applications:
1).IEEE 802.3bm 100GBASE SR4
2).ProprietaryHighSpeedInterconnections
3).Datacenter
Electrical Characteristics:

Optical Characteristics:
Digital Diagnostic Functions:
The following digital diagnostic characteristics are defined over the normal operating conditions unless otherwise specified.

Main Export Countries & Areas:
Usa, Uk, Japan, Germany, Spain, France, Swiss, Korea, Russia, Mexico, Brazil, Argentina,Pakistan, India, Portugal, Canada, New Zealand, Australia, Saudi Arab, Turkey, Finland, Poland ,etc.
Payment Method: by T/T or Western Union.
Delivery time: 7-10 days.
Quality Warranty: Ruitaiphotoelectric(Raytekoptics) offers quality warranty for our optical transceiver products with "3R" policy. For any inferior-quality products, Ruitaiphotoelectric(Raytekoptics) is responsible for return, replacement and refund.
