Description
General Introduction: Raytek's high energy Nd: YAG laser is made of high purity fused silica substrate and superhard dielectric coating. After relevant testing and certification, the product can withstand high energy pulse and has high damage threshold.
Products Name: High-Energy Nd:YAG Laser Mirrors
Alias: High-Energy Nd:YAG Laser Mirrors, Nd:YAG Laser Mirrors,Laser Mirrors,YAG laser Mirrors, Laer reflective mirrors, YAG laser reflectors, etc
Mirrors Substrates:
High purity fused silica substrate
Coating:
Ultrahard dielectric coatings.
Main Applying:
Main Characters:
1).Design of superhard dielectric coating
2).Superhard dielectric coating with high damage threshold up to 40J / cm2
3).Single wavelength, dual wavelength mirror, RS > 99.7%, RS > 99%
4).Dual wavelength mirror, wavelength range 1064 - 532 nm
5).UV fused silica substrate, low thermal expansion, low absorption
Products Highlights:
1).Different grades materials for option.
2).High precision & high surface roughness;
3).Sizes can be customized as per the customers' request
4).Quick lead time and delivery time.
5).Matching super optics custom and processing capacity, including Moulding, CNC machining, Polishing, Particle beam processing, Magnetic flux conversion processing, Grinding, Coating, Lightweighting, Custom Shaping, Counterbores, Drilling & Coring, Edge & Bevel Polishing,3D Contouring, Bevels & Chamfers, Steps & Slots, Laser Cutting & Marking, Metrology & Inspection, Precision Pitch Polishing, Double-Sided Polishing, Optical Assembly, Measuring, etc.
6).Excellent post-sale quality warranty, with "3R"-return, replace & refund policy
Main Optical Tech Specification:
Popular Physical Size Specification:
Main Cooperation Materials Manufacturers:
CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,ETC
Main Export Countries & Areas:
Products Name: High-Energy Nd:YAG Laser Mirrors
Alias: High-Energy Nd:YAG Laser Mirrors, Nd:YAG Laser Mirrors,Laser Mirrors,YAG laser Mirrors, Laer reflective mirrors, YAG laser reflectors, etc
Mirrors Substrates:
High purity fused silica substrate
| Optional I: |
High purity fused silica substrate from CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,ETC |
| Optional II: |
Equivalent High purity fused silica substrate Made in China, C-laser own brands |
Coating:
Ultrahard dielectric coatings.
Main Applying:
| Applying Fields I: | High-Energy Nd:YAG Laser |
| Applying Fields II: | Other |
| ***** |
|
Main Characters:
1).Design of superhard dielectric coating
2).Superhard dielectric coating with high damage threshold up to 40J / cm2
3).Single wavelength, dual wavelength mirror, RS > 99.7%, RS > 99%
4).Dual wavelength mirror, wavelength range 1064 - 532 nm
5).UV fused silica substrate, low thermal expansion, low absorption
Products Highlights:
1).Different grades materials for option.
2).High precision & high surface roughness;
3).Sizes can be customized as per the customers' request
4).Quick lead time and delivery time.
5).Matching super optics custom and processing capacity, including Moulding, CNC machining, Polishing, Particle beam processing, Magnetic flux conversion processing, Grinding, Coating, Lightweighting, Custom Shaping, Counterbores, Drilling & Coring, Edge & Bevel Polishing,3D Contouring, Bevels & Chamfers, Steps & Slots, Laser Cutting & Marking, Metrology & Inspection, Precision Pitch Polishing, Double-Sided Polishing, Optical Assembly, Measuring, etc.
6).Excellent post-sale quality warranty, with "3R"-return, replace & refund policy
Main Optical Tech Specification:
| Tech Data | Description |
| Wavelength Range | 266 nm, 354.7 nm, 532 nm, 1064 nm |
| Angle of Incidence | - |
| Coating Type | Ultrahard dielectric coatings. |
| Reflectivity | - |
| Damage Threshold | - |
| Material | UV Grade Fused Silica |
| Surface Quality | 10-5 scratch-dig, 15-5 scratch-dig |
| Surface Flatness | λ/10 at 632.8 nm |
| Clear Aperture | ≥central 80% of diameter |
| Chamfers | - |
| Chamfers Angle Tolerance | - |
| Wedge | ≤3 arc min |
Popular Physical Size Specification:
| Mirror Size | 25.4 mm, 50.8 mm or custom manufacturing |
| Thickness | 6.35 mm, 8.0 mm, 9.65 mm, 12.5 mm or custom manufacturing |
| Thickness Tolerance | - |
| Diameter | 25.4 mm, 50.8 mm or custom manufacturing |
| Diameter Tolerance | - |
Main Cooperation Materials Manufacturers:
CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,ETC
Main Export Countries & Areas:
Usa, Uk, Japan, Germany, Spain, France, Swiss, Korea, Russia, Pakistan, India, Portugal, Canada, New Zealand, Australia, Saudi Arab, Turkey, Finland, Poland ,etc.
Raytekoptics Extra value added services offered:
1). Optical workcraft & process solution design;
2). Rough processing raw materials;
3). Semi finishing raw materials;
4). Fabricate custom sizes and shapes;
5). Design and supply custom coatings;
6). Modify and resurface customer supplied materials;
7). Drill holes, notch glass and provide beveled substrates;
8). Precision polish optics with non-standard aspect ratios;
Payment Method: by T/T or Western Union.
Delivery time: 7-10 days.
Quality Warranty: Ruitaiphotoelectric(Raytekoptics) offers quality warranty for our optics products with "3R" policy. For any inferior-quality products, Ruitaiphotoelectric(Raytekoptics) is responsible for return, replacement and refund.
