Description
General Introduction: The Raytek high-energy parallel window is made of low scattering excimer level UV fused silica, and the high-energy Nd: YAG laser system is optimized. Each surface of the product is covered with antireflection film with high efficiency and high damage threshold..
Products Name: Laser protection window
Alias:Laser Line windows, Laser Line optical lens, Laser line lens, Laser line parallel windows, Laser parallel windows,etc
Lens Substrates:
Excimer Grade UV Fused Silica
Coating:
The application of Nd: YAG laser is optimized
Each surface of our high energy parallel window is coated with a high efficiency, high damage threshold V coating. The coating can be used to maximize the transmission at 1064 nm, 532nm, 355nm and 266nm, corresponding to the first, second, third and fourth harmonic of Nd: YAG laser, respectively.
Main Optical Tech Specification:
Main Cooperation Materials Manufacturers:
CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,ETC
Main Export Countries & Areas:
Products Name: Laser protection window
Alias:Laser Line windows, Laser Line optical lens, Laser line lens, Laser line parallel windows, Laser parallel windows,etc
Lens Substrates:
Excimer Grade UV Fused Silica
| Optional I: |
Excimer Grade UV Fused Silica from CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,ETC |
| Optional II: |
Equivalent Excimer Grade UV Fused Silica Made in China, C-laser own brands |
Coating:
The application of Nd: YAG laser is optimized
Each surface of our high energy parallel window is coated with a high efficiency, high damage threshold V coating. The coating can be used to maximize the transmission at 1064 nm, 532nm, 355nm and 266nm, corresponding to the first, second, third and fourth harmonic of Nd: YAG laser, respectively.
Main Optical Tech Specification:
| Lens Shape | Optical Parallel Window |
Surface Accuracy Irregularity |
- |
| Lens Material | Excimer Grade UV Fused Silica | Diameter Tolerance | - |
| Coating | Laser Line V coating | Angle of incidence | 00 |
| Coating Type | - | Thickness | 3.0mm |
| Damage Threshold | - | Dia. Tolerance | +0/-0.10 mm |
| Thickness Tolerance | ±0.10 mm | Parallelism | 5 arc seconds |
| Surface Quality | 10-5cratch-dig | Clear Aperture | Central 90% of diameter |
| Surface Flatness | λ/10 @ 632.8nm | OEM/ODM | Accepted |
Main Cooperation Materials Manufacturers:
CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,ETC
Main Export Countries & Areas:
Usa, Uk, Japan, Germany, Spain, France, Swiss, Korea, Russia, Pakistan, India, Portugal, Canada, New Zealand, Australia, Saudi Arab, Turkey, Finland, Poland ,etc.
Raytekoptics Extra value added services offered:
1). Optical workcraft & process solution design;
2). Rough processing raw materials;
3). Semi finishing raw materials;
4). Fabricate custom sizes and shapes;
5). Design and supply custom coatings;
6). Modify and resurface customer supplied materials;
7). Drill holes, notch glass and provide beveled substrates;
8). Precision polish optics with non-standard aspect ratios;
Payment Method: by T/T or Western Union.
Delivery time: 7-10 days.
Quality Warranty: Ruitaiphotoelectric(Raytekoptics) offers quality warranty for our optics products with "3R" policy. For any inferior-quality products, Ruitaiphotoelectric(Raytekoptics) is responsible for return, replacement and refund.
