Description
Product Description:Wedge prisms, also known as wedge prisms, are optical devices with inclined planes. Wedge prisms are mainly used in the field of optics for beam control offset. The inclination of the two sides of the wedge prism is relatively small, which can deflect the light path to the thicker side. If only one wedge prism is used, the incident light path can be angled at a certain angle. The offset of the two wedge prisms can be used as an anamorphic prism when used in combination, mainly used to correct the laser beam. In the optical field, wedge prism is an ideal optical path adjustment device, and two rotatable prisms can adjust the direction of the outgoing beam within a certain range.
Product data:
Product material: UV fused silica, BK7
Dimensional tolerance: +0.0,-0.1mm
Thickness tolerance: &plun; 0.2mm
Wedge angle: &plun; 1 point
Surface shape: λ /
Finish: 60-40
Product data:
Product material: UV fused silica, BK7
Dimensional tolerance: +0.0,-0.1mm
Thickness tolerance: &plun; 0.2mm
Wedge angle: &plun; 1 point
Surface shape: λ /
Finish: 60-40
Inverted angle: < 0.25mm* 45°
Main Cooperation Materials Manufacturers:
CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,ETC
Main Export Countries & Areas:
Usa, Uk, Japan, Germany, Spain, France, Swiss, Korea, Russia, Pakistan, India, Portugal, Canada, New Zealand, Australia, Saudi Arab, Turkey, Finland, Poland ,etc.
Raytekoptics Extra value added services offered:
1). Optical workcraft & process solution design;
2). Rough processing raw materials;
3). Semi finishing raw materials;
4). Fabricate custom sizes and shapes;
5). Design and supply custom coatings;
6). Modify and resurface customer supplied materials;
7). Drill holes, notch glass and provide beveled substrates;
8). Precision polish optics with non-standard aspect ratios;
Payment Method: by T/T or Western Union.
Delivery time: 7-10 days.
Quality Warranty: Ruitaiphotoelectric(Raytekoptics) offers quality warranty for our optics products with "3R" policy. For any inferior-quality products, Ruitaiphotoelectric(Raytekoptics) is responsible for return, replacement and refund.
