Description
General Introduction: Fireplace special glass is fireplace glass, all kinds of fireplace temperature is very high, some even contact with open fire, which makes fireplace need a special kind of glass. Fireplace glass has superior temperature difference resistance, high temperature resistance and good transparency. It is the best matching product for fireplace.
Fireplace as a heating equipment has been widely used in all kinds of families, safer, higher temperature resistance is the biggest internal factor in favor of fireplace glass.
Fireplace glass, as a kind of high temperature glass installed on the fireplace, is not only beautiful but also energy-saving, which can effectively prevent the smoke from entering the room, but also prevent the burning flame from escaping out of the door of the fireplace. The fireplace glass has a high thermal conductivity, which can transfer heat to the room and seal the wall furnace mouth. It can effectively observe the combustion situation and flame size in the furnace door, and has obvious energy-saving effect.
The fireplace glass is made of fine-grained glass. The maximum short-term heat resistance of fine-grained glass is 1000 degrees, and the safe working temperature is within 800 degrees. The temperature of wood flame is generally not more than 560 degrees. Therefore, the fireplace glass made of fine-grained glass can completely resist the erosion of flame and will not be burned by flame
Products Name: Fireplace glass/High temperature-resistant glass/ULE glass/Low Expansion Rateglass/Safety glass/Fine-grained glass
Alias: Fireplace glass,High temperature-resistant glass,ULE glass,Low Expansion Rate glass,Safety glass,Fine-grained glass, Anti-high temperature glass,glass-ceramic, ceramic glass,etc
Main Technical Data of Fireplace Glass:
Physical, Chemical,Thermal properties:
Other Glass Types In Purpose:
Processing Workcrafts:
1. Cutting
2. Chamfering
3. Inverted edge
4. Surface precision polishing
5. Drilling
6. Coating
7. Surface printing and sandblasting
Fireplace as a heating equipment has been widely used in all kinds of families, safer, higher temperature resistance is the biggest internal factor in favor of fireplace glass.
Fireplace glass, as a kind of high temperature glass installed on the fireplace, is not only beautiful but also energy-saving, which can effectively prevent the smoke from entering the room, but also prevent the burning flame from escaping out of the door of the fireplace. The fireplace glass has a high thermal conductivity, which can transfer heat to the room and seal the wall furnace mouth. It can effectively observe the combustion situation and flame size in the furnace door, and has obvious energy-saving effect.
The fireplace glass is made of fine-grained glass. The maximum short-term heat resistance of fine-grained glass is 1000 degrees, and the safe working temperature is within 800 degrees. The temperature of wood flame is generally not more than 560 degrees. Therefore, the fireplace glass made of fine-grained glass can completely resist the erosion of flame and will not be burned by flame
Products Name: Fireplace glass/High temperature-resistant glass/ULE glass/Low Expansion Rateglass/Safety glass/Fine-grained glass
Alias: Fireplace glass,High temperature-resistant glass,ULE glass,Low Expansion Rate glass,Safety glass,Fine-grained glass, Anti-high temperature glass,glass-ceramic, ceramic glass,etc
Main Technical Data of Fireplace Glass:
| Technical Data | Description & Value |
| Product Name | High temperature resistant fireplace glass |
| Temperature-resistant range | 800-1000ºC |
|
|
Max.high temperature resistance 1000ºC |
|
|
Long time heat resistant 760ºC |
|
|
Sudden temperature difference between hot&cold:700ºC |
| Light transmittance | 90% |
| Mohs hardness | 6 |
| Fire resistance | directly contact with open fire |
| Safety grade | A |
| Specification size | 300*400mm, 600*545mm, 600*600mm,or customized |
| Standard thickness | 4mm, 5mm, or customize |
| Color | Light tawny, Dark, Beige,etc or customize |
Physical, Chemical,Thermal properties:
| Technical Data | Description & Value |
| Mechanical properties |
|
|
|
Density at 25ºC,2.53-2.55g/cm3 |
|
|
Modulus of elasticity (E): about. 93 x 103 MPa |
| Thermal properties |
Coefficient of thermal expansion 20-700ºC(0+- 0.5)*10-6K-1 |
|
|
Heat capacity: CP (20-100ºC) 0.8k "* (KQ * k) - 1 |
|
|
Thermal conductivity: a (90ºC) 1.6W * (m * k) - 1 |
| Temperature difference performance of the same sheet |
The temperature difference between the center and the edge of the glass sheet is the temperature difference that the glass sheet can bear That is, in TMax≤760ºC will not crack due to thermal stress! The value of thermal shock resistance means that the glass sheet can withstand the temperature change That is, in TMax≤760ºC will not crack due to thermal stress |
| Chemical properties |
Water resistance iso719 / din12111 HGB1 Acid resistance iso1776 / din12116 3 Alkali resistance iso695 / din52322 A2 |
Other Glass Types In Purpose:
| Type | Description |
| Applying 1 | Hot pot furnace panel, wave soldering, furnace and fireplace panel. |
| Applying 2 | Protection panel of electric heater, high performance spotlight and floor lamp. |
| Applying 3 | Red ultraviolet drying equipment. |
| Applying 4 | Such as infrared drying equipment, UV protection equipment, barbecue plate, laboratory and high temperature welding mask, safety glass, etc. |
| Applying 5 | Wood burning fireplace, electric fireplace, real fire fireplace, etc. |
| Applying 6 | It is widely used in gas fireplace, real fire fireplace and other series products, especially suitable for the field with great temperature difference and strong temperature impact. |
| Applying 7 | Wave soldering, fireplace and oven equipments |
Processing Workcrafts:
1. Cutting
2. Chamfering
3. Inverted edge
4. Surface precision polishing
5. Drilling
6. Coating
7. Surface printing and sandblasting
8. Hot bending
Main Export Countries & Areas:
Usa, Uk, Japan, Germany, Spain, France, Swiss, Korea, Russia, Pakistan, India, Portugal, Canada, New Zealand, Australia, Saudi Arab, Turkey, Finland, Poland ,etc.
Payment Method: by T/T or Western Union.
Delivery time: 7-10 days.
Quality Warranty: Ruitaiphotoelectric(Raytekoptics) offers quality warranty for our optics products with "3R" policy. For any inferior-quality products, Ruitaiphotoelectric(Raytekoptics) is responsible for return, replacement and refund.
